Specification:
1.Material Loading Shelf
2. Ф50 exactitude extruder
Screw:
High strength stainless steel(9Cr18Mo),high precision screw(soft PVC)
Screw Dia:50MM
Screw ratio: 28:1
Raw material feeder:
High-strength nitride alloy steel , 38CrMoALA High Precision inner circle Grinding
Main driven part:
SIEMENS,driven power:11KW
ABB Inverter Motor Controller
motor power:11KW
high precision and low noise grinding Tooth, high-torque gear reducer
Main motor heating:
High efficiency heater;
Solid-state relay control
Japan RKC temperature table;
High-efficiency ultra-quiet cooling fan control
3.Die and Mould
High-precision stainless steel head :1set
High-precision stainless steel mould:1set
4.cooling tank
Cooling tank length:4M
Tank body:2MM( thickness) Stainless Steel Bending Forming
Front and rear removable rack
5. small belt tractor
High-precision guide system;
Single-screw center height adjustment, loose and tighten co-regulation;
High efficiency, synchronous traction belt with wear-resistant surface ;
Low Inertia Pulley;
invertor :1.5KW FUJI ,japan
High efficiency, high-precision worm gear driven ;
Auto alarm
4-digit auto meter;
Blowing and drying set
Center height:1M
Belt length: 680×60 mm
Punching cutting power:0.37KW:
6. 5P chiller
|
