MODEL

MWK-45A

MWK-50A

MWK-45A-2

MWK-55A-2

SUITABLE MATERIAL

HDPE

LDPE

FILM WIDTH (mm)

300-600

300-800

100-400x2

100-500x2

FILM THICKNESS (HD) mm

0.009-0.05

0.009-0.05

0.009-0.05

0.01-0.05

                  (LD)mm

0.025-0.11

0.025-0.11

0.025-0.11

0.025-0.11

MAX.EXTRUSION OUTPUT（HD）

40kg/hr

50kg/hr

45kg/hr

75kg/hr

                   (LD)

45kg/hr

70kg/hr

60kg/hr

100kg/hr

SCREW DIAMETER(mm)

φ45

φ50

φ55

φ55

SCREW L/D LENGTH

28:1

SCREW MATRIAL

SACM-645/38 CRMOALA

CYLINDER MATRIAL

SACM-645/38 CRMOALA

CYLIDER COOLING

370w×2

370w×2

370w×2

550w×3

DRIVING MOTOR (kw)

11

15

15

22

TEMPERATURE CONTROL

3

3

3

4

AVERAGE POWER-CONSUME (kw)

18

26

18

30

DIE SIZE(mm)

60/80

80/100

45/60×2

60/80×2

                    (LD)mm

150

180

120×2

150×2

TEMPERATURE CONTROL

3

3

3×2

3×2

AIR RING

1

1

1×2

1×2

AIR BLOWER (kw)

1.5

2.2

1.5×2

2.2×2

CENTER STEADY STICK

2

2.2×2

PINCH ROLLER (DIA.WIDTH)mm

φ165×650

φ165×850

φ 165×450×2

φ165×500×2

HIGHT ADJUSTABLE TYPE

700mm

TAKE-UP SPEED(m/min)

10-100

10-100

10-100

10-80

TAKE-UP MOTOR (kw)

0.75

1.5

0.75×2

0.75×2

TYPE

SURFACE FRICTION TYPE

WINDING MOTOR(kw)

5

10

5 -2

5 -2

WINDING SPEED (m/min)

10-100

10-100

10-100

10-80

COVER DIMENSION

5.0×2.0×4.1

5..2×2.2×4.5

5.5×2.8×4.1

5.8×3.2×4.5
