Opening Milling Machine

Special note
Opening Milling Machine
Details
Parameter
Opening Milling Machine (3inch)
　
Cooling type (MWK-76L)
Electric Heating type(MWK-76)
Roller
actual using length≈15cm ，
（ф76mm×L 150mm）
Ratio
1:1.16, actual 8.6:10rev./min.
Temperature
Normal temperature-tap water℃
max：normal +10--300℃adjustable
Temperature control
　
Temperature controller is using high precisoin P I D intelligent microcomputer control system
,higher precisoin than manual setting; with over-temperature warning function to protect machine and production material
Motor
0.3HP，opening could be adjustable; normal opeing0.2-3mm
0.5HP，opening could be adjustable; normal opeing0.2-3mm
Safety system
brake safety rail, finger touch to stop and revese at some angle; safety rail is on the above of the wheel; emergeny stop rail is supported by spring
brake safety rail, finger touch to stop and revese at some angle; safety rail is on the above of the wheel;
Machine dimension
80*40*50cm
80*40*40cm
Machine weight
within 80kg
within 100kg
Machine structure
Steel plate;
 ( more light than traditional casting iron, small dimension, high mechanical strength and good toughness ）
Roller Stand has security protective cover, refusing sundries enter and avoiding manpower injury. There are two wear-resistant high-temperature profiles at the two ends of roller for the flexible adjusting for width. Any qty of refining rubber could be achieved.
Little refining rubber: adjust to the middle/
Much refining rubber: adjust to both sides.
Power
2∮，AC220V，3A
Power
50W
Motor
Taiwan
Relay
Japan OMRON
Roller material
Japan SKD die steel
